Today we visited our customer in Shibuya Tokio. near the famous Cerulean tower shown above.
A medium sized company needed a fast server for a database. We recommended the hardware and installed the server on their premises.
Today we also installed Windows Server and prepared the settings for thedata base hosting.
As the Internet connection on site is not compatible with the server we also helped to choose the best internet connection and get the right service form the network provider.
Recently we had securely wipe out the configuration data of a few cisco routers at LoreaTec and I thought it could be useful to post it here. After you complete the steps bellow the router will be back to factory settings, the same as when you bought it new.
The command output may be a little different depending on the model but with the steps bellow you should be able to wipe the data of most CISCO routers.
I have marked in RED the commands you need to input to make it clearer. The rest is explanation or router output example.
1-Turn on the router. Before the prompt loads press Ctrl+C (on some models you need to press Ctrl+Enter+Break) and you will see the as bellow.
Self decompressing the image :
#######################
monitor: command “boot” aborted due to user interrupt
rommon 1 >
2-Enter?confreg 0x2142 as you see bellow:
rommon 1 > confreg 0x2142
rommon 2 >
3-Now it says rommon 2 > enter reset? command so that the router reboots.
rommon 2 > reset
System Bootstrap, Version 12.3(8r)T8, RELEASE SOFTWARE (fc1)
Cisco 1841 (revision 5.0) with 114688K/16384K bytes of memory.
Self decompressing the image :
########################################################################## [OK]
Restricted Rights Legend
Use, duplication, or disclosure by the Government is
subject to restrictions as set forth in subparagraph
(c) of the Commercial Computer Software – Restricted
Rights clause at FAR sec. 52.227-19 and subparagraph
(c) (1) (ii) of the Rights in Technical Data and Computer
Software clause at DFARS sec. 252.227-7013.
cisco Systems, Inc.
170 West Tasman Drive
San Jose, California 95134-1706
Cisco IOS Software, 1841 Software (C1841-ADVIPSERVICESK9-M), Version 12.4(15)T1, RELEASE SOFTWARE (fc2)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2007 by Cisco Systems, Inc.
Compiled Wed 18-Jul-07 04:52 by pt_team
Image text-base: 0x60080608, data-base: 0x6270CD50
This product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.
A summary of U.S. laws governing Cisco cryptographic products may be found at:
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
If you require further assistance please contact us by sending email to
export@cisco.com.
Cisco 1841 (revision 5.0) with 114688K/16384K bytes of memory.
Processor board ID FTX0947Z18E
M860 processor: part number 0, mask 49
2 FastEthernet/IEEE 802.3 interface(s)
2 Low-speed serial(sync/async) network interface(s)
191K bytes of NVRAM.
63488K bytes of ATA CompactFlash (Read/Write)
Cisco IOS Software, 1841 Software (C1841-ADVIPSERVICESK9-M), Version 12.4(15)T1, RELEASE SOFTWARE (fc2)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2007 by Cisco Systems, Inc.
Compiled Wed 18-Jul-07 04:52 by pt_team
4- It asks you if you want to continue with configuration dialog. Enter n en press enter two times.
— System Configuration Dialog —
Continue with configuration dialog? [yes/no]:n
Press RETURN to get started!
Router>
5-escribis enable
Router>enable
Router#
6-Write startup-config and press enter key.
Router#erase startup-config
7-Write erase startup-config and press enter key again.
Erasing the nvram filesystem will remove all configuration files! Continue? [confirm] Press enter key
[OK]
Erase of nvram: complete
%SYS-7-NV_BLOCK_INIT: Initialized the geometry of nvram
Router#
8-Write conf t or configure terminal to continue with the router set up.
Router#conf t
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)#
9-Write config-register 0x2102
Router(config)#config-register 0x2102
Router(config)#
10-Write end to make the router go back to factory settings.
Router(config)#end
%SYS-5-CONFIG_I: Configured from console by console
Router#
11-Write reload to process and save all the changes and let it boot.
Router#reload
Proceed with reload? [confirm]
%SYS-5-RELOAD: Reload requested by console. Reload Reason: Reload Command.
ySystem Bootstrap, Version 12.3(8r)T8, RELEASE SOFTWARE (fc1)
Cisco 1841 (revision 5.0) with 114688K/16384K bytes of memory.
Self decompressing the image :
########################################################################## [OK]
Restricted Rights Legend
Use, duplication, or disclosure by the Government is
subject to restrictions as set forth in subparagraph
(c) of the Commercial Computer Software – Restricted
Rights clause at FAR sec. 52.227-19 and subparagraph
(c) (1) (ii) of the Rights in Technical Data and Computer
Software clause at DFARS sec. 252.227-7013.
cisco Systems, Inc.
170 West Tasman Drive
San Jose, California 95134-1706
Cisco IOS Software, 1841 Software (C1841-ADVIPSERVICESK9-M), Version 12.4(15)T1, RELEASE SOFTWARE (fc2)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2007 by Cisco Systems, Inc.
Compiled Wed 18-Jul-07 04:52 by pt_team
Image text-base: 0x60080608, data-base: 0x6270CD50
This product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.
A summary of U.S. laws governing Cisco cryptographic products may be found at:
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
If you require further assistance please contact us by sending email to
export@cisco.com.
Cisco 1841 (revision 5.0) with 114688K/16384K bytes of memory.
Processor board ID FTX0947Z18E
M860 processor: part number 0, mask 49
2 FastEthernet/IEEE 802.3 interface(s)
2 Low-speed serial(sync/async) network interface(s)
191K bytes of NVRAM.
63488K bytes of ATA CompactFlash (Read/Write)
Cisco IOS Software, 1841 Software (C1841-ADVIPSERVICESK9-M), Version 12.4(15)T1, RELEASE SOFTWARE (fc2)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2007 by Cisco Systems, Inc.
Compiled Wed 18-Jul-07 04:52 by pt_team
— System Configuration Dialog —
Continue with configuration dialog? [yes/no]:
12-Select no and you are back to the initial prompt. Now the router has the same settings as when it was bought.
Continue with configuration dialog? [yes/no]: n
Press RETURN to get started!
Router>
Please link to this post if the information was useful. Please contact us at LoreaTec if you have any comments or if there is any mistake.
